Spring-based Parallax with Framer motion: Step by step

This guide is using an older version of framer motion (v4). I'm currently updating this post to use the new useScroll API which makes this a lot easier. In the meantime I recommend checking the

useScroll

documentation.

Parallax scrolling has gotten a bad rap, but I believe that's in part because of the very poor implementations out there. As with everything, if we're mindful and make it subtle it can help convey our message more clearly. There's a simple thing you can do to greatly improve the effect: Use a spring-based easing.

Let's take a look at the Epic React course landing page:

This is an example of a parallax transition implemented the right way. If you scroll super-quickly you will still see the animation, and if you use a mouse-wheel it never stutters. This is because the animation is eased and not mapped 1:1 to the actual scroll. This way the effect looks super nice! (And most importantly, it makes sense on this landing page and helps deliver the message).

Another website that does this right is Quill.chat, notice how when you scroll through the site you get a sense of joy when the elements smoothly slide into view with just the right velocity. Had they not eased the movement if wouldn't have felt as good.

I'm convinced - How to implement parallax spring easing with react?

You can implement parallax scrolling in a lot of different ways, for this example I'm using my favourite animation framework Framer Motion to create a reusable <Parallax /> component. You can do similar things with other frameworks like react-spring or as descibed here by Paul Lewis & Robert Flack on the google developer blog. If you already know the basics of parallax scrolling feel free to skip to the section adding the spring easing.

Let's start by creating a component that accept children as a prop.

import { ReactNode } from 'react'

type ParallaxProps = {
  children: ReactNode
}

const Parallax = ({ children }: ParallaxProps): JSX.Element => {
  return children
})

export default Parallax

Next up we'll import useViewportScroll from framer-motion in order to get how far on the page we have scrolled. We'll use this as the input to another framer-motion hook called useTransform in order to calculate our parallax values which we'll add to a motion.div.

Using Framer Motion useTransform

useTransform takes an input value and a transformer, and outputs a new value. For example:

// The output value will always be double that of `x`.
const y = useTransform(x, (value) => value * 2);

Lets start by using some random values to see that it's working:

import { ReactNode } from 'react'
import { motion, useViewportScroll, useTransform } from 'framer-motion'

type ParallaxProps = {
  children: ReactNode
}

const Parallax = ({ children }: ParallaxProps): JSX.Element => {
  const { scrollY } = useViewportScroll()
  const y = useTransform(scrollY, [100, 200], [0, 500])

  return <motion.div style={{ y }}>{children}</motion.div>
})

export default Parallax

In order to find out the correct values we need to add some calculations. The idea is that the component should be centered in it's container when we've scrolled to the middle of the screen, but offset by x pixels when scrolled in either direction.

In order to do this we need two values: what the offsetTop of our element is and the height of the screen. Let's add a ref to our element and use useLayoutEffect to save those values when the component is about to mount.

import { useState, useRef, useLayoutEffect, ReactNode } from 'react'
import { motion, useViewportScroll, useTransform } from 'framer-motion'

type ParallaxProps = {
  children: ReactNode
  offset?: number
}

const Parallax = ({ children, offset = 50 }: ParallaxProps): JSX.Element => {
  const [elementTop, setElementTop] = useState(0)
  const [clientHeight, setClientHeight] = useState(0)
  const ref = useRef(null)

  const { scrollY } = useViewportScroll()

  // start animating our element when we've scrolled it into view
  const initial = elementTop - clientHeight
  // end our animation when we've scrolled the offset specified
  const final = elementTop + offset

  const y = useTransform(scrollY, [initial, final], [offset, -offset])

  useLayoutEffect(() => {
    const element = ref.current
    // save our layout measurements in a function in order to trigger
    // it both on mount and on resize
    const onResize = () => {
      // use getBoundingClientRect instead of offsetTop in order to
      // get the offset relative to the viewport
      setElementTop(element.getBoundingClientRect().top + window.scrollY || window.pageYOffset)
      setClientHeight(window.innerHeight)
    }
    onResize()
    window.addEventListener('resize', onResize)
    return () => window.removeEventListener('resize', onResize)
  }, [ref])

  return (
    <motion.div ref={ref} style={{ y }}>
      {children}
    </motion.div>
  )
})

export default Parallax

There's a lot going on here so let's break it down.

  1. We've added an offset prop to specify how strong we want our effect to be.
  2. We create a ref that we'll use to measure our element
  3. We setup our state where we'll save elementTop and clientHeight.
  4. We add a useLayoutEffect where we set those values so we can calculate the start and end for our transformer.

  5. Finally we put it all together in the useTransform function to get our new y value.

Adding spring easing with useSpring

In order to get the smooth easing we talked about earlier we need to transform our new y value with a spring. We can do it with the useSpring hook.

import { useState, useRef, useLayoutEffect, ReactNode } from 'react'
import { motion, useViewportScroll, useTransform, useSpring } from 'framer-motion'

type ParallaxProps = {
  children: ReactNode
  offset?: number
}

const Parallax = ({ children, offset = 50 }: ParallaxProps): JSX.Element => {
  const [elementTop, setElementTop] = useState(0)
  const [clientHeight, setClientHeight] = useState(0)
  const ref = useRef(null)

  const { scrollY } = useViewportScroll()

  // start animating our element when we've scrolled it into view
  const initial = elementTop - clientHeight
  // end our animation when we've scrolled the offset specified
  const final = elementTop + offset

  const yRange = useTransform(scrollY, [initial, final], [offset, -offset])
  // apply a spring to ease the result
  const y = useSpring(yRange, { stiffness: 400, damping: 90 })

  useLayoutEffect(() => {
    const element = ref.current
    // save our layout measurements in a function in order to trigger
    // it both on mount and on resize
    const onResize = () => {
      // use getBoundingClientRect instead of offsetTop in order to
      // get the offset relative to the viewport
      setElementTop(element.getBoundingClientRect().top + window.scrollY || window.pageYOffset)
      setClientHeight(window.innerHeight)
    }
    onResize()
    window.addEventListener('resize', onResize)
    return () => window.removeEventListener('resize', onResize)
  }, [ref])

  return (
    <motion.div ref={ref} style={{ y }}>
      {children}
    </motion.div>
  )
})

export default Parallax

Parallax accessibility: useReducedMotion

When designing products with motion we have to be careful and think about people who might have problems viewing things that move around. Some people can get dizzy or nauseous. You can specify this by a setting in you operating system, for example on MacOS the setting is in "Accessibility > Reduce Motion".

Luckily there's a Media Query for this called prefers-reduced-motion, and a useful hook exported by framer motion called useReducedMotion.

If the user prefers reduced motion we will render the children directly without our parallax container:

import { useState, useRef, useLayoutEffect, ReactNode } from "react";
import {
  motion,
  useViewportScroll,
  useTransform,
  useSpring,
  useReducedMotion,
} from "framer-motion";

type ParallaxProps = {
  children: ReactNode;
  offset?: number;
};

const Parallax = ({ children, offset = 50 }: ParallaxProps): JSX.Element => {
  const prefersReducedMotion = useReducedMotion();
  const [elementTop, setElementTop] = useState(0);
  const [clientHeight, setClientHeight] = useState(0);
  const ref = useRef(null);

  const { scrollY } = useViewportScroll();

  const initial = elementTop - clientHeight;
  const final = elementTop + offset;

  const yRange = useTransform(scrollY, [initial, final], [offset, -offset]);
  const y = useSpring(yRange, { stiffness: 400, damping: 90 });

  useLayoutEffect(() => {
    const element = ref.current;
    const onResize = () => {
      setElementTop(
        element.getBoundingClientRect().top + window.scrollY ||
          window.pageYOffset
      );
      setClientHeight(window.innerHeight);
    };
    onResize();
    window.addEventListener("resize", onResize);
    return () => window.removeEventListener("resize", onResize);
  }, [ref]);

  // Don't parallax if the user has "reduced motion" enabled
  if (prefersReducedMotion) {
    return <>{children}</>;
  }

  return (
    <motion.div ref={ref} style={{ y }}>
      {children}
    </motion.div>
  );
};

export default Parallax;

Wrapping up

Our finished component:

Parallax

We've learned how we can create a parallax effect with Framer Motion, improve it by applying a spring easing and taking care of the accesibility aspect with useReducedMotion. Check out the full source code of our Framer Motion example in my git repo, and make sure to ❤️ the post below if you liked it, or reach out to me on twitter for any comments or questions!
